Fieldbus Access
CAN COMMUNICATION
Fieldbus access with J1939 and CANopen available out-of-the-box.
Fieldbus Access is a module for easy access to control J1939 and CANopen communication. The module takes care of the whole complexity of the high-level CAN protocols, letting the software developer focus on access and usage of the signals and data.
The module includes a CAN message configurator, integrated into the Qt development environment, keeping everything in one place, and everything managed in the same Qt project.
| SPECIFICATION | |
| Integrated configurator | Integrated signal management into Qt Creator |
| J1939 and CANopen | Freely select J1939 or CANopen on any of the available CAN interfaces on the display. You can even use J1939 or CANopen on several interfaces at the same time |
| Extensive message type support | Support for CANopen slave, including PDOs, SDOs and network management. Support for J1939, including PGNs, SPNs and DMs |
| DBC file import | Import your own DBC file, for easy access and usage of your own system variables |
| EDS file generation | Generate an EDS file from your CANopen slave configuration that can be imported into the CANopen master in the system |
